Tech4POD - Equivalent Text Description

Existing single-plane fluoroscopy system

Photograph shows a single-plane fluoroscopy system.

Brief Description:

Photograph shows a single-plane fluoroscopy system.

Essential Description:

A photo of the dynamic biplane x-ray imager with components. An artificial leg is posed in the picture to illustrate the interaction of the person and the imager.

Detailed Description:

The model of a human foot with a shoe on is placed on a force plate with an x-ray source on the one side and an image intensifier on the other side which together produce a 2D image. The force plate is silver and the model of a human foot is black.
