Top View of Foot Plate

Diagram shows a schematic of foot plates in a pivoting-sliding elliptical system.

Brief Description:

Diagram shows a schematic of foot plates in a pivoting-sliding elliptical system.

Essential Description:

This is a drawing of a right and left pivot-sliding foot plate for an elliptical training system. Arrows indicate the direction of movement of certain components.

Detailed Description:

The drawing provides details visible on the top of the foot plate. Both a right and left side are shown and allow for foot pivot movement by turning the heel. Each plate can also slide side to side on a bracket on the foot plate.
